Santa Cruz 5010 C S MX - 2023

Santa Cruz 5010 C S MX
  • Color: Matte Nickel
$6,799.00
Please select options
This item can be purchased online and picked up curbside from our store.

Details

The 5010 is not just "the little bike" of our range. It makes even the most mundane trails feel like they're loaded with features to hop, skip and jump over. It's like having super-skills at your fingertips. The 5010 has always been more capable than many expected but with the traction-gaining 29-inch wheel up front and even more refined suspension the 5010 gives you a deft touch on the trails.

Mixed Wheels
The mixed wheel configuration of a 29-inch wheel up front provides traction and stability, while the 27.5" rear wheel allows for quick back wheel steering and lifting.


HIGH

Geometry Chart:
SizeX-SmallSmallMediumLargeX-LargeXX-Large
FLIP CHIP (hi/lo) HI HI HI HI HI HI
REACH (mm) 410 434 459 479 499 524
STACK HT (mm) 599 608 622 631 649 662
ANGLE HT 65.2 65.2 65.2 65.2 65.2 65.1
LENGTH ST (mm) 90 100 115 125 145 160
ANGLE ST 77.4 77.4 77.4 77.1 77.3 77.3
ST LENGTH (mm) 370 380 405 430 460 500
REAR CENTER (mm) 428 430 433 436 439 442
FRONT CENTER (mm) 719 748 779 803 832 863
BB HEIGHT (mm) 338 338 338 338 338 338
F/R BB DROP (mm) 35/16 35/16 35/16 35/16 35/16 35/16
WHEELBASE (mm) 1147 1178 1212 1239 1271 1305
TT LENGTH (mm) 544 570 598 624 645 673
STANDOVER (mm) 694 703 706 708 711 717

LOW

Geometry Chart:
SizeX-SmallSmallMediumLargeX-LargeXX-Large
FLIP CHIP (hi/lo) LO LO LO LO LO LO
REACH (mm) 406 431 456 476 496 521
STACK HT (mm) 601 610 624 633 651 664
ANGLE HT 64.9 64.9 64.9 64.9 64.9 64.9
LENGTH ST (mm) 100 100 115 125 145 160
ANGLE ST 75.9 77.1 77.1 76.8 77 77.1
ST LENGTH (mm) 370 380 405 430 460 500
REAR CENTER (mm) 429 431 434 437 440 443
FRONT CENTER (mm) 718 748 779 803 832 863
BB HEIGHT (mm) 335 335 334 334 334 335
F/R BB DROP (mm) 38/19 38/19 38/19 38/19 38/19 38/19
WHEELBASE (mm) 1147 1178 1213 1240 1271 1306
TT LENGTH (mm) 544 571 599 625 646 674
STANDOVER (mm) 688 698 700 703 706 712

Specs

Frame Carbon C MX 130mm Travel VPP
Fork RockShox Pike Select+, 140mm
Rear Shock RockShox Super Deluxe Select+, 210x50
Rims Front: RaceFace AR Offset 30 29" Rim
Rear: RaceFace AR Offset 30 27.5" Rim
Hubs Front: DT Swiss 370, 15x110, Torque Cap, 28h
Rear: DT Swiss 370, 12x148, XD, 36t, 28h
Tires Front: Maxxis Minion DHR II 29"x2.4", 3C MaxxGrip, EXO, TR
Rear: Maxxis Minion DHR II 27.5"x2.4", 3C MaxxTerra, EXO, TR
Bottom Bracket SRAM DUB 68/73mm Threaded BB
Crankset SRAM GX Eagle 148 DUB, 32t
Shifters SRAM GX Eagle, 12spd
Rear Derailleur SRAM GX Eagle, 12spd
Cassette/Freewheel SRAM XG1275 Eagle, 12spd, 10-50t
Chain SRAM GX Eagle, 12spd
Brakes SRAM G2 R
Rotors Front: Avid Centerline 200mm
Rear: Avid Centerline 180mm
Handlebars Burgtec RideWide Alloy Bar, 800mm
Tape/Grips Santa Cruz Bicycles House Grips
Stem Burgtec Enduro MK3, 42mm
Headset Cane Creek 40 IS Integrated Headset
Seatpost RockShox Reverb Stealth, 31.6
Saddle WTB Silverado Medium CroMo

* Subject to change without notice.

Part Numbers

Option MPN Store SKU
Matte Nickel / Large 58-23283-148-4-770-888901 5011361053G
Gloss Red / Medium 58-23283-148-3-771-888901 50113702559D
